FUJI NXT PICKIUP HEIGHT MEASUREMENT JIG
FUJI SMT machine parts are high-quality original parts designed for FUJI series SMT machines, and are widely used in various models of SMT machines such as NXT series and XP series. These parts ensure the efficient operation of SMT production lines with their excellent performance, high precision and reliability, and help customers achieve high-efficiency and high-quality production goals.
Product Features:
The Pickup Height Measurement Jig is designed for FUJI NXT systems to accurately measure and calibrate nozzle pickup heights.
Built to OEM specifications, it provides precise and repeatable measurements during machine setup and maintenance.
Application Advantages:
It simplifies calibration tasks, reducing setup time and improving placement accuracy.
Its durable construction ensures long-term reliability, minimizing errors and supporting stable SMT production performance.
Fuji Spare Parts List
| Part Number | Part Name | Description | Function Used |
|---|---|---|---|
| 2MDLFF1388 | Motor BKT | Stacked stick feeder | |
| 2MDLFF1391 | Motor | Stacked stick feeder | |
| 2MDLFF1416 | Gear | NXT II | |
| 2MDLFF1417 | Side Plate | Stacked stick feeder | |
| 2MDLFF1418 | Side Plate | Stacked stick feeder | |
| 2MDLFF1419 | Guide Plate | Stacked stick feeder | |
| 2MDLFF1420 | Guide Plate | Stacked stick feeder | |
| 2MDLFF1421 | Guide | Stacked stick feeder | |
| 2MDLFF1422 | Guide | Stacked stick feeder | |
| 2MDLFF1449 | Pin | Stacked stick feeder | |
| 2MDLFF1500 | Guide | Stacked stick feeder | |
| 2MDLFF1520 | Guide Plate | NXT III | |
| 2MDLFF1521 | Guide Plate | NXT Feeder | |
| 2MDLFF1522 | Spacer | NXT III | |
| 2MDLFF1523 | Spacer | NXT III | |
| 2MDLFF1536 | Collar | Stacked stick feeder | |
| 2MDLFF1537 | Shaft | Stacked stick feeder | |
| 2MDLFF1550 | Holder | Stacked stick feeder | |
| 2MDLFF1551 | Work Retainer | Stacked stick feeder | |
| 2MDLFF1552 | Pivot Pin | Stacked stick feeder |
